Catalog Number: PBCTT84X120


  • Aids Transfer of Insulating Glass Units or Single Lites of Glass

  • Raises and Lowers by Pneumatic Cylinder Action

  • All Tubular Steel Construction with Adjustable Legs
  • Solid Vertical Glass Rest Included
  • Roller Toe Options Available

  • The CRL Power Ball Caster Tilt Table tilts to a vertical 84 degree position for the lateral transfer of single sheets of glass or insulating glass units. Its heavy 2" (51 mm) square by 1/8" (3 mm) thick tubular steel construction supports any size load. There is a solid wooden 2 x 6 pressure treated fixed position vertical glass rest. The neoprene casters are 2" (51 mm) diameter spherical balls that will not scratch the glass. The table height can be adjusted from 34" to 36" (863 to 914 mm). When leveled at a 36" (914 mm) transfer height, the vertical wooden glass rest will be positioned 8-5/8" (219 mm) from the floor.



    CRL 84" x 120" Power Ball Caster Tilt Table





    Other Products/Finishes:

    CATALOG NUMBER DESCRIPTION
    PBCTT84X120 CRL 84" x 120" Power Ball Caster Tilt Table
    PBCTT84X144 CRL 84" x 144" Power Ball Caster Tilt Table
    PBCTT84X156 CRL 84" x 156" Power Ball Caster Tilt Table
    PBCTT84X168 CRL 84" x 168" Power Ball Caster Tilt Table
    PBCTT84X192 CRL 84" x 192" Power Ball Caster Tilt Table

    Catalog Number:PBCTT84X120
    Also Available in These Catalogs:
    CRL73R Tools, Machinery, and Equipment, PAGE 626K
    GMB15 Glass Machinery Brochure, PAGE MB07
    Table Top Size:84" x 120" (2.13 x 3.05 m)
    F.O.B :Cicero, Il.
    Shipping Weight:600 lb (272.16kg)

    NOTE: 100 psi, seven cfm air supply is required for operation. System ships partially disassembled to reduce freight. Customer must attach legs and ball casters. All hardware included.

    Always wear the proper protective safety gear including safety glasses when moving glass across the caster table.
