PH11ELA - CRL Satin Anodized LH European Bottom Door Patch Fitting
C.R.Laurence
 YOUR ACCOUNT               VIEW CART                SIGN INSIGN OFF
Search


View Larger Image

Catalog Number: PH11ELA
Finish: SATIN ANODIZED


  • For 3/8" or 1/2" (10 or 12 mm) Tempered Glass

  • 2-9/16" (65 mm) Pivot Setback

  • For Herculiteā„¢+ Style Doors


  • For Use With:
  • 3/8" or 1/2" (10 or 12 mm) Tempered Glass
  • Glass Fabrication Required: One 3/4" (19 mm) Diameter
  • Hole and Corner Notch
  • Template is available at crlaurence.com.


  • CRL Satin Anodized LH European Bottom Door Patch Fitting





    Other Products/Finishes:

    CATALOG NUMBER DESCRIPTION COLOR
    PH11ELA CRL Satin Anodized LH European Bottom Door Patch Fitting
    PH11ELBS CRL Brushed Stainless LH European Bottom Door Patch Fitting
    PH11ELMBL CRL Matte Black LH European Bottom Door Patch Fitting
    PH11ELPS CRL Polished Stainless LH European Bottom Door Patch Fitting
    PH11ERA CRL Satin Anodized RH European Bottom Door Patch Fitting
    PH11ERBS CRL Brushed Stainless RH European Bottom Door Patch Fitting
    PH11ERMBL CRL Matte Black RH European Bottom Door Patch Fitting
    PH11ERPS CRL Polished Stainless RH European Bottom Door Patch Fitting

    Catalog Number:PH11ELA
    Also Available in These Catalogs:
    AH18 Architectural Hardware Catalog 2018, PAGE 210Z
    Color:Satin Anodized
    Ship Via:Can Ship UPS
    Minimum Order:1 Each

    Includes:
  • 1 Each AMR201 Door Patch
  • 1 Each 1NT305L and 1NT305R Bottom Door Patch Insert
  • Gaskets for 3/8" or 1/2" (10 or 12 mm) Glass

  • For maximum door size when using this product, CRL follows GANA Guidelines.
