Catalog Number: PH21CA
Finish: SATIN ANODIZED


  • Adjustable Pivot Insert Allows Three Degrees Movement for Proper Door Alignment

  • 2-9/16" (65 mm) Pivot Setback

  • For 3/8" or 1/2" (10 or 12 mm) Glass


  • The CRL Adjustable Top Door Patch Fitting includes an adjustable pivot insert that allows for 3 degrees of movement for proper alignment of the door to the jamb when in the closed position. For use with our CRL9970 Overhead Concealed Door Closer. Finished covers are available in five standard finishes. Gaskets are supplied that allow this Patch Fitting to be used with either 3/8" or 1/2" (10 or 12 mm) Glass.



    CRL Satin Anodized Adjustable European Top Door Patch Fitting





    Other Products/Finishes:

    CATALOG NUMBER DESCRIPTION COLOR
    PH21CA CRL Satin Anodized Adjustable European Top Door Patch Fitting
    PH21CBR CRL Brass Adjustable European Top Door Patch Fitting
    PH21CBS CRL Brushed Stainless Adjustable European Top Door Patch Fitting
    PH21CDU CRL Dark Bronze Adjustable European Top Door Patch Fitting
    PH21CMBL CRL Matte Black Adjustable European Top Door Patch Fitting
    PH21CPS CRL Polished Stainless Adjustable European Top Door Patch Fitting
    PH21CSB CRL Satin Brass Adjustable European Top Door Patch Fitting

    Catalog Number:PH21CA
    Also Available in These Catalogs:
    AH18 Architectural Hardware Catalog 2018, PAGE 209Z
    CRL63A Architectural Hardware Master, PAGE 372H
    CRL93A Architectural Hardware, PAGE CH122
    Color:Satin Anodized
    Ship Via:Can Ship UPS
    Shipping Weight:1 lb (454g)
    Minimum Order:1 Each

    The following guidelines are to be used when making a door using this hardware:

    Maximum Height: 102" (2.59 m)
    Maximum Weight: 194 Lbs. (88 kg)
    Maximum Width: 42" (1.09 m)

    If the door exceeds any of these limitations, full door rails should be used.

    GLASS FABRICATION REQUIRED:
    One 3/4" (19 mm) Diameter
    Hole and Corner Notch

    COMES WITH:
    Template and Instructions

    These fittings are not for use with Laminated Glass. The following guidelines are to be used when making a 1/2" glass door using this hardware: Maximum Height: 102" (2.59 m) Maximum Height: 176 Lbs. (80 kg) Maximum Width: 42" (1.09 m) If the door exceeds any of these limitations, full door rails should be used.
